Product Description
Lever Operated Butterfly Valve is easily accessible with a single movement and allow uniform air flow. This has superior corrosion resistance and are suitable for a variety of industrial applications. Durability, ease of installation, robust construction, good performance, and optimum tensile strength are all features of this product. Lever Operated Butterfly Valve in question has a trouble-free operation. In an advanced pneumatic system, this is used to control and alter the flow of air. This valve is very cost effective and can be easily purchased by people, at reasonable prices.
Lever Operated Butterfly Valve Specifications:
|
End Connection:
|
Wafer - API 609 (CAT - A)
|
|
Range:
|
DN40 - DN300
|
|
Suitable to:
|
ASMI B16.5 150#, BS10 TABLE : E, F, H
|
|
Pressure Range:
|
PN10, PN16
|
|
Leakage Class:
|
100% Tightness at fully differential pressure
|
|
Standard:
|
API 609, BS 5155, ISO 5211, API 598, ASME B16.5
|
|
Body Material:
|
Cast Iron, WCB, SS304, SS316
|
|
Disc Material:
|
SGI, CF8, CF8M
|
|
Stem Material:
|
SS 410, SS 304, SS 316
|
|
Body Liner / Seat Material:
|
NBR, EPDM
|
Lever Operated Butterfly Valve Features:
- Bi-directional zero leakage butterfly valve.
- ISO Pad for mounting, Gear Operator /Actuator
- Extremely small play between the stem and disc due to Double D drive.
- Accurate dual stem sealing prevents leakage.
- Butterfly valve can be mounted between flanges as per ASME, BS-10.
- 100% tested under Water and Pneumatic.
- 360 degree disc rotation.
- Design Standard : ISO 5211, API 609, ASME B16.5 150#.
- Nominal Diameter : DN40 -DN300.
- Pressure Rang (bar) : PN10, PN16.
- ANSI B16.5 150#, BS10 TABLE E, TABLE F, TABLE H, Flange Accommodation.
- Face to Face Dimension : API 609 (CAT A).
- Operator mounting flange : As per ISO 5211.
- Operator : Hand Lever / Gear / Actuator.
- End connection : wafer end.
- Leakage Class : 100% tightness at full differential Pressure
